Product Overview
With the Viqua VH410-F20 Model system you provide yourself one of the most sought-after brands in the UV industry. Viqua rigorously tests all its products to ensure they are of the highest standards. The VH410-F20 Model is an 18 GPM point-of-entry system for homes that combines a pre-treatment sediment filter with UV purification to combat microorganisms and small particles commonly found in water. This system features state of the art UV sensor technology, 2X the UV-C output of standard low-pressure lamp technology, a lamp age indicator, stainless steel chamber, and 120 AC voltage. This quality system is simple to install and maintain.
- Adds integral 5 micron pre-filtration module to the VH410 UV system
- Mounted on a reversible, heavy duty, painted steel bracket for installation flexibility and convenience
Documentation:
Spec Sheet
User Manual
| DISINFECTION FLOW RATES | ||
| 16mJ/cm2 | 34 GPM (130 lpm) (7.8 m3/hr) | |
| 30mJ/cm2 | 18 GPM (70 lpm) (4.2 m3/hr) | |
| 40mJ/cm2 | 14 GPM (54 lpm) (3.3 m3/hr) | |
| SPECIFICATIONS | ||
| Dimensions | 17″ x 10 1/2″ x 28″ (43 cm x 26 cm x 71 cm) | |
| Shipping Weight lbs (kg) | 32 lbs (14.5 kg) | |
| Connection Size | 1″MNPT INLET / 1″ x 3/4″ COMBO OUTLET (/2B – BSP) | |
| Power Consumption | 60W |
