Rainier 5.0 Commercial Water Treatment System
LUMINOR's RAINIER 5.0 model is a commercial water treatment system, designed with upgradeability in mind. The reactor comes with an integral UV sensor port that will accept the addition of an optional UV sensor module at a future date. If a monitor is not required, an integral visual glow plug is provided as an extra way to ensure that your UV lamp is illuminated. Manufactured from 316L stainless steel, these pressure vessels are designed & manufactured to ASME standards. A bayonet style lamp connector allows for easy lamp change without the need for additional tools. For increased power density, RAINIER incorporates high quality low pressure, amalgam (LP-AM) coated UV lamps offering a consistent output over their 12,000 hour life. Monitoring is provided through an integral LED display which outputs remaining lamp life, total running hours, audible & visual lamp failure, remote-on and solenoid ready. Whether you are looking to control microbiological (bacteria & virus) issues in both hot or cold water with UVT levels as low as 50% or to reduce TOC in industrial grade waters, RAINIER has you covered.
Luminor RAINIER 5.0 UV Features:
- Available in 110V/60Hz. or 230V/50-60Hz.
- Modular control panel with LED display for UV output, remaining lamp life, total running hours, audible & visual lamp failure, remote on and solenoid ready
- 316L stainless steel, polished reactors, with integral sensor port to allow for sensor upgradeability in the future (comes standard with visual glow plug)
- Designed & manufactured to ASME pressure vessel standards
- Reliable, industry proven low pressure amalgam (LP-AM) coated UV lamps with ceramic bases for durability, 12,000 hour lamp life
- Uniform lamp output in both hot or cold applications
- Flexible vertical or horizontal installation
- User friendly bayonet style lamp connector (quick ¼ turn removal with no extra tools needed)
- True gland seal retaining nut with positive stop
- Constant current electronic controller in a splash-proof (IP-54) case with audible and visual lamp failure indicators
RAINIER5.0, Light Commercial Amalgam UV Systems, non-monitored
| Model | LR5-355 | LR5-555 | LR5-855 | LR5-1105 | LR5-1405 | LR5-1755 |
|---|---|---|---|---|---|---|
| Flow Rate 30 mJ/cm² @ 95% UVT (Industry Std.) |
35 gpm | 58 gpm | 85 gpm | 110 gpm | 140 gpm | 175 gpm |
| 132 lpm | 220 lpm | 322 lpm | 416 lpm | 530 lpm | 662 lpm | |
| 8.0 m³/hr | 13.2 m³/hr | 19.3 m³/hr | 25.0 m³/hr | 31.8 m³/hr | 39.7 m³/hr | |
| Alternate Flow Rate 16 mJ/cm² @ 95% UVT (US Public Health)* |
66 gpm | 109 gpm | 167 gpm | 207 gpm | 263 gpm | 327 gpm |
| 250 lpm | 413 lpm | 632 lpm | 784 lpm | 996 lpm | 1240 lpm | |
| 15.0 m³/hr | 24.8 m³/hr | 37.9 m³/hr | 47.0 m³/hr | 59.7 m³/hr | 74.3 m³/hr | |
| Alternate Flow Rate 40 mJ/cm² @ 95% UVT |
27 gpm | 44 gpm | 67 gpm | 84 gpm | 106 gpm | 131 gpm |
| 102 lpm | 167 lpm | 252 lpm | 318 lpm | 401 lpm | 496 lpm | |
| 6.1 m³/hr | 10.0 m³/hr | 15.1 m³/hr | 19.1 m³/hr | 24.1 m³/hr | 29.8 m³/hr | |
| Port Size | 1½" | 2" | 2" | 2½" | 3" | 4" |
| Electrical | 230V / 50-60Hz (IEC power cords required) |
|||||
| Plug Type | North American NEMA 6/15: "5" suffix European CEE 7/7: "2" suffix British BS1363: "3" suffix" Australian AS/NZ 3112: "4" suffix |
|||||
| Lamp Watts | 104 | 152 | 207 | 304 | 344 | 414 |
| Power (watts) | 120 | 170 | 220 | 320 | 360 | 430 |
| Replacement Lamp | RL-500A | RL-720A | RL-1000A | RL-720A (2 required) |
RL-843A (2 required) |
RL-1000A (2 required) |
| Replacement Sleeve | RQ-500 | RQ-720 | RQ-1000 | RQ-720 (2 required) |
RQ-843 (2 required) |
RQ-1000 (2 required) |
| Chamber Material | 316L Stainless Steel, A249 Pressure Rated Tubing, Polished & Passivated | |||||
| Reactor Dimensions | 4x27.2x5.6" 10x69x14cm |
4x35.8x5.6" 10x91x14cm |
4x46.8x5.6" 10x119x14cm |
6x35.8x7.9" 15x91x20cm |
6x40.6x7.9" 15x103x20cm |
6x46.8x7.9" 15x119x20cm |
| Controller Dimensions | 11.8 x 7.9 x 6.3" (30.0 x 20.1 x 16.0 cm) | |||||
| Maximum Operating Pressure | 10.3 bar (150 psi) | |||||
| Operating Temperature Range | 2-40° C (36-104° F) | |||||
| UV Monitor | Upgradeable, includes visual glow plug | |||||
| Remote-On | Yes, with optional 210010 cable | |||||
| Dry Contacts (solenoid ready) | Yes, with optional 210010 cable | |||||
| 4-20 mA Output | Yes, with optional 210010 cable | |||||
| Lamp Age Counter | Yes | |||||
| Lamp-Out Indicator (audible & visual) | Yes | |||||
| *Note: | based on flow velocity of 8.2 ft/s (2.5 m/s), flow rates are limited by port sizes: 1½": 52gpm (197 lpm) 2": 85.8gpm (325 lpm) 2½": 122.4 gpm (463 lpm) 3": 189 gpm (715 lpm) 4": 325.4 gpm (1232 lpm) |
|||||
Documentation:
Replacement Parts:
| Model | Sleeve | Lamp |
| LR5-355 | RQ-500 | RL-500A |
| LR5-555 | RQ-720 | RL-720A |
| LR5-855 | RQ-1000 | RL-1000A |
| LR5-1105 | RQ-720 | RL-720A (system requires 2 lamps/sleeves) |
| LR5-1405 | RQ-843 | RL-843A (system requires 2 lamps/sleeves) |
| LR5-1755 | RQ-1000 | RL-1000A (system requires 2 lamps/sleeves) |
Warranty Information
LIMITATIONS OF WARRANTY
This warranty does not apply to any of the following:
Water Quality Parameters lie outside of the following range:
Hardness 120 mg/L (7 gpg)
Iron 0.3 mg/L (ppm)
Manganese 0.05 mg/L (ppm)
Tannins 0.1 mg/L (ppm)
Turbidity 0.1 NTU
Transmittance (UVT) 75% (50% for Low-UVT systems)
A product that has been incorrectly installed according to the technical installation manual.
A product that has been modified in any manner, unless approved by the manufacturer.
A product where the serial number has been altered defaced or removed.
Damage caused by the use of parts that are not compatible, suitable and/or authorized by LUMINOR for use with the product (e.g. non-original lamps or sleeves).
Damage caused during shipment of the product.
Water damage is found inside ballast housing or controllers.
Product is installed outdoors in direct contact with the environment (rain).
Product is installed in freezing temperatures.
Product is used in conditions that exceed LUMINOR’s specifications.
TO GET WARRANTY SERVICE
To obtain service under this warranty, you must first contact LUMINOR Customer Service at 855-837-3801 (519-837-3800 outside of the US or Canada) to obtain a Warranty Return Authorization.
You will then need to return the product through the LUMINOR Dealer or Distributor where the product was originally purchased, together with proof of purchase and installation date, failure date, and supporting installation data. Unless otherwise provided, the Dealer or Distributor will contact LUMINOR for instructions on returning the product. Any defective product to be returned to LUMINOR must be sent freight prepaid; documentation supporting the warranty claim and/or a Return Material Authorization must be included if so instructed.
LUMINOR WILL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSSES, OR EXPENSES ARISING FROM INSTALLATION, USE, OR ANY OTHER CAUSES. THERE ARE NO EXPRESS OR IMPLIED WARRANTIES, INCLUDING MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, WHICH EXTEND BEYOND THOSE WARRANTIES DESCRIBED OR REFERRED TO ABOVE.
THIS LIMITED WARRANTY IS THE SOLE AND EXCLUSIVE WARRANTY MADE BY LUMINOR WITH RESPECT TO THE PRODUCT, AND IS GIVEN IN LIEU OF ANY OTHER WARRANTY. TO THE EXTENT ALLOWED BY APPLICABLE LAW, ANY AND ALL EXPRESS OR IMPLIED WARRANTIES NOT SET FORTH HEREIN ARE WAIVED AND DISCLAIMED, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE. LUMINOR LIABILITY UNDER THIS LIMITED WARRANTY IS LIMITED SOLELY TO THOSE LIABILITIES SET FORTH ABOVE. IN THE EVENT THAT ANY PROVISION OF THIS LIMITED WARRANTY SHOULD BE OR BECOME INVALID OR UNENFORCEABLE UNDER APPLICABLE LAW, THE REMAINING TERMS AND CONDITIONS HEREOF SHALL REMAIN IN FULL FORCE AND EFFECT AND SUCH INVALID OR UNENFORCEABLE PROVISION SHALL BE CONSTRUED IN SUCH A MANNER AS TO BE VALID AND ENFORCEABLE.
